ComboBox

The ComboBox presents a selected item and a drop-down button that displays a list of options. The length and height of the combo box are determined by the selected item, unless otherwise defined.

The items in the list can be composed, bound and templated.

info

To review the concept behind data templates, see here.

Useful Properties

You will probably use these properties most often:

Property	Description
Items	The list items collection.
SelectedIndex	The index (zero-based) of the selected item.
SelectedItem	The selected item itself.
SelectedItems	A collection of selected items that has more than one item when selection mode is set to multiple.
AutoScrollToSelectedItem	Indicates whether to automatically scroll to newly selected items.
IsDropDownOpen	Indicates whether the dropdown is currently open.
MaxDropDownHeight	The maximum height for the dropdown list. This is the actual height of the list part, not the number of items that show.
ItemPanel	The container panel to place items in. By default, this is a StackPanel. See this page to customise the ItemsPanel.
Styles	The style that is applied to any child element of the ItemControl.

Examples

This is basic example with text items has a limit set on the drop-down list height.

<StackPanel Margin="20">
  <ComboBox SelectedIndex="0" MaxDropDownHeight="100">
    <ComboBoxItem>Text Item 1</ComboBoxItem>
    <ComboBoxItem>Text Item 2</ComboBoxItem>
    <ComboBoxItem>Text Item 3</ComboBoxItem>
    <ComboBoxItem>Text Item 4</ComboBoxItem>
    <ComboBoxItem>Text Item 5</ComboBoxItem>
    <ComboBoxItem>Text Item 6</ComboBoxItem>
    <ComboBoxItem>Text Item 7</ComboBoxItem>
    <ComboBoxItem>Text Item 8</ComboBoxItem>
    <ComboBoxItem>Text Item 9</ComboBoxItem>
  </ComboBox>
</StackPanel>

This example uses a composed view for each item:

<StackPanel Margin="20">
  <ComboBox SelectedIndex="0">
    <ComboBoxItem>
      <Panel>
        <Ellipse Width="50" Height="50" Fill="Red"/>
        <TextBlock VerticalAlignment="Center"
                    HorizontalAlignment="Center">Red</TextBlock>
      </Panel>
    </ComboBoxItem>
    <ComboBoxItem>
        <Panel>
          <Ellipse Width="50" Height="50" Fill="Orange"/>
          <TextBlock VerticalAlignment="Center"
                      HorizontalAlignment="Center">Amber</TextBlock>
        </Panel>
    </ComboBoxItem>
    <ComboBoxItem>
      <Panel>
        <Ellipse Width="50" Height="50" Fill="Green"/>
        <TextBlock VerticalAlignment="Center"
                    HorizontalAlignment="Center">Green</TextBlock>
      </Panel>
    </ComboBoxItem>
  </ComboBox>
</StackPanel>

This example binds the items in a combo box using a data template. The C# code-behind loads the installed font family names and binds them to the items property.

<StackPanel Margin="20">
  <ComboBox x:Name="fontComboBox" SelectedIndex="0"
            Width="200" MaxDropDownHeight="300">
    <ComboBox.ItemTemplate>
      <DataTemplate>
        <TextBlock Text="{Binding Name}" FontFamily="{Binding}" />
      </DataTemplate>
    </ComboBox.ItemTemplate>
  </ComboBox>
</StackPanel>

C#

using Avalonia.Controls;
using Avalonia.Media;
using System.Linq;

namespace AvaloniaControls.Views
{
    public partial class MainWindow : Window
    {
        public MainWindow()
        {
            InitializeComponent();
            fontComboBox.Items = FontManager.Current
                .GetInstalledFontFamilyNames()
                .Select(x => new FontFamily(x))
                .OrderBy(x=>x.Name);
            fontComboBox.SelectedIndex = 0;
        }
    }
}

More Information

info

For the complete API documentation about this control, see here.

info

View the source code on GitHub ComboBox.cs
