Defining properties

Defining properties for custom controls

If you are creating a custom control, you will usually want it to have properties that can be set by the Avalonia styling system, bound to data, or configured in XAML. Avalonia provides three property types for this purpose: styled properties, direct properties, and attached properties.

This page walks you through registering and using each type so you can choose the right one for your control.

info

For more information about how to use styles in Avalonia, see the Styles guide.

Styled properties

A styled property is the most common property type. It stores its value inside the Avalonia property system (not in a backing field), which means it participates in styling, animations, and value precedence. Use a styled property when you want users to be able to style or animate the property.

Registering a styled property is a two-step process:

Register the property as a static readonly field using AvaloniaProperty.Register.
Provide a CLR getter and setter that call GetValue and SetValue.

Naming convention

The static field must follow the pattern PropertyNameProperty. Avalonia uses this convention to map XAML attributes to properties automatically:

public static readonly StyledProperty<double> CornerRadiusProperty = ...

This lets you write the following in XAML:

<local:MyControl CornerRadius="8" />

Registering a new styled property

The following example registers a CornerRadius styled property with a default value of 0.0:

public class MyControl : Control
{
    public static readonly StyledProperty<double> CornerRadiusProperty =
        AvaloniaProperty.Register<MyControl, double>(nameof(CornerRadius), defaultValue: 0.0);

    public double CornerRadius
    {
        get => GetValue(CornerRadiusProperty);
        set => SetValue(CornerRadiusProperty, value);
    }
}

The Register method accepts several optional parameters:

Parameter	Description
`name`	The property name. Must match the CLR property name.
`defaultValue`	The default value for the property.
`inherits`	Whether the value inherits down the visual tree.
`defaultBindingMode`	The default binding mode (`OneWay`, `TwoWay`, `OneTime`, `OneWayToSource`).
`validate`	A function that returns `false` for values that should be rejected.
`coerce`	A function that adjusts the value before it is applied.

Reusing an existing styled property

If another control already defines a property you need (for example, Background on Border), use AddOwner instead of registering a new one. This ensures a single property identity so that styles targeting the property work across all controls that share it:

public class MyCustomControl : Control
{
    public static readonly StyledProperty<IBrush?> BackgroundProperty =
        Border.BackgroundProperty.AddOwner<MyCustomControl>();

    public IBrush? Background
    {
        get => GetValue(BackgroundProperty);
        set => SetValue(BackgroundProperty, value);
    }
}

Styling a custom property

Once you register a styled property, users can target it in styles. The following example sets the Background of a custom control through a style:

MainWindow.axaml
<Window xmlns="https://github.com/avaloniaui"
        xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
        xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
        xmlns:cc="using:AvaloniaCCExample.CustomControls"
        xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
        mc:Ignorable="d" d:DesignWidth="800" d:DesignHeight="450"
        x:Class="AvaloniaCCExample.MainWindow"
        Title="Avalonia Custom Control">

  <Window.Styles>
    <Style Selector="cc|MyCustomControl">
      <Setter Property="Background" Value="Yellow"/>
    </Style>
  </Window.Styles>

  <cc:MyCustomControl Height="200" Width="300"/>

</Window>

MyCustomControl.cs
using Avalonia;
using Avalonia.Controls;
using Avalonia.Media;

namespace AvaloniaCCExample.CustomControls
{
    public class MyCustomControl : Control
    {
        public static readonly StyledProperty<IBrush?> BackgroundProperty =
            Border.BackgroundProperty.AddOwner<MyCustomControl>();

        public IBrush? Background
        {
            get { return GetValue(BackgroundProperty); }
            set { SetValue(BackgroundProperty, value); }
        }

        public sealed override void Render(DrawingContext context)
        {
            if (Background != null)
            {
                var renderSize = Bounds.Size;
                context.FillRectangle(Background, new Rect(renderSize));
            }
            base.Render(context);
        }
    }
}

The styled property works both at run-time and in the preview panel.

Preview of a custom control with a defined property

Direct properties

A DirectProperty is backed by a conventional C# field. It does not participate in styling or animation, but it supports data binding and change notification. Use a direct property when:

You need a read-only property (styled properties cannot be read-only).
You want better performance because the value is read directly from the field.
The property does not need to be styled (for example, Items on ItemsControl).

Registering a direct property

Use AvaloniaProperty.RegisterDirect and provide getter and setter delegates that point to your backing field:

public class MyControl : Control
{
    public static readonly DirectProperty<MyControl, string?> StatusProperty =
        AvaloniaProperty.RegisterDirect<MyControl, string?>(
            nameof(Status),
            o => o.Status,
            (o, v) => o.Status = v);

    private string? _status;

    public string? Status
    {
        get => _status;
        set => SetAndRaise(StatusProperty, ref _status, value);
    }
}

warning

Always use SetAndRaise in the CLR setter instead of assigning the backing field directly. SetAndRaise updates the field and raises the property-changed notification in a single call. Calling SetValue on a direct property will throw an exception.

Read-only direct properties

To create a read-only property, omit the setter delegate from the registration call and keep the CLR setter private:

public class MyControl : Control
{
    public static readonly DirectProperty<MyControl, bool> IsActiveProperty =
        AvaloniaProperty.RegisterDirect<MyControl, bool>(
            nameof(IsActive),
            o => o.IsActive);

    private bool _isActive;

    public bool IsActive
    {
        get => _isActive;
        private set => SetAndRaise(IsActiveProperty, ref _isActive, value);
    }
}

Styled vs. direct properties

Behavior	Styled property	Direct property
Participates in styling	Yes	No
Participates in animations	Yes	No
Supports value precedence	Yes	No (single value)
Can inherit values	Yes	No
Supports coercion	Yes	No
Performance	Property store lookup	Direct field access
Can be read-only	No	Yes

Responding to property changes

You can react to property value changes by overriding OnPropertyChanged in your control:

protected override void OnPropertyChanged(AvaloniaPropertyChangedEventArgs change)
{
    base.OnPropertyChanged(change);

    if (change.Property == BackgroundProperty)
    {
        // Invalidate the visual so the control repaints with the new background.
        InvalidateVisual();
    }
}

This approach works for both styled and direct properties.

Common pitfalls

Mismatched names. The name argument you pass to Register must match the CLR property name exactly. A mismatch causes binding and XAML errors at run-time.
Using SetValue with a direct property. Direct properties require SetAndRaise. Calling SetValue throws an InvalidOperationException.
Adding a backing field for a styled property. Styled properties store values inside the Avalonia property system. If you read from a local field you will get stale data. Always use GetValue and SetValue.
Forgetting to call base.OnPropertyChanged. If you override OnPropertyChanged, always call the base implementation first so the framework can process the change.
